品牌  Brand

苏华特  SUHUATE

型号  Type

SHT2403

电 器 系 统

  Electrical system

电控  Electric control

72V智能化控制系统；无级调速，制动断电，欠压保护，过流保护等性能，稳定。72V 控制器，强劲快速，自动修复。72V intelligent control system; Stepless speed regulation, braking power off, undervoltage protection, overcurrent protection and other performance, stable. 72V controller, powerful, fast, automatic repair.

电池  Battery

72V 20Ah 大容量铅酸电池72V 20Ah large-capacity lead-acid battery

电机  Motor

72V 1000W 永磁直流无刷电机；高效电机，动力强劲，高效节能，续航里程长。72V 1000W permanent magnet DC brushless motor; High efficiency motor, powerful power, high efficiency and energy saving, long driving range.

电路系统  Circuit system

全车防水、阻燃插件，骑行更安全Whole waterproof, flame retardant plug-in, more safe riding

充电器  Charger

72V20Ah 锂电充电器，耐用、安全、充电平稳、耐高温72V20Ah lithium charger, durable, safe, stable charging, high temperature resistance

充电时间  Charging time

6-8小时  6-8 hours

车 身 配 置

Body matching

车体  Body

钢制车架+塑料外壳  Steel frame + plastic shell

仪表  Instrument panel

多功能黑莓全面屏数码仪表盘，功能齐全Multifunctional blackberry Full screen digital dashboard, full of features

车架  Frame

高强度钢结构件；整车采用大踏板，前后避震，结构硬朗、扎实、稳定。high-strength steel structure; The whole vehicle adopts large pedal, front and rear shock absorber, the structure is strong, solid and stable.

前叉  Front fork

液压带阻尼无缝管材质，外加塑料防护套Hydraulic belt damped seamless tube material, plus plastic protective jacket

灯光及信号  Lights and signals

透镜LED大灯，前照灯，前左、右转向灯：组合后尾灯，配置左、右转向灯。电喇叭；凌厉霸气的水晶的前大灯，按照仿生学原理设计，外形更美观，照明更安全Lens LED headlights, headlights, front left and right turn signals: combined rear taillights, equipped with left and right turn signals. Electric horn; The crystal headlights are designed according to the principle of bionics, which makes the appearance more beautiful and the lighting more safe

P档  P file

点动式开关，车辆启动更安全  Point switch, vehicle start safer

遥控器及防盗器Remote control unit and burglar alarm

配置智能化遥控器，智能化防盗器  Intelligent remote control, intelligent anti-theft device

前减震

 Front shock absorber

无缝，阻尼，双管液压  Seamless, damped, dual hydraulic

后减震  Rear shock absorber

倒置结构，带阻尼  Inverted structure with damping

底 盘

  Bottom plate

动力传动系统

 Power transmission system

无级调速系统   Stepless speed control system

驱动系统    Drive system

后轴驱动   Rear axle drive

制动系统    Brake system

前碟刹,后鼓刹，性能优越   Front disc brake, rear drum brake, superior performance

外形尺寸 长*宽*高(mm)

Size Length * Width * Height (mm)

1850mm×520mm×1150mm

轴距    Wheelbase

1330mm

轮胎    Tyre

300-10 真空轮胎    300-10 vacuum tires

制动距离    Braking distance

≤6.5 m

最大行驶速度

Maximum travel speed

≤47km/h

续驶里程    Range

≤65Km

最大爬坡度

 Maximum gradient

≤30°

充电输入电压    Charge input voltage

220v

品牌

Brand

苏华特

型号

Type

SHT2496

电 器 系 统

电控

Electric control

72V智能化控制系统；无级调速，制动断电，欠压保护，过流保护等性能，稳定。72V 12管 控制器，强劲快速。

72V intelligent control system; It has stable performance features such as stepless speed regulation, power cut-off during braking, under-voltage protection, over-current protection, etc. A 72V 12-tube controller provides strong and rapid performance.

电池

Battery

72V 20AH,  6只大容量深循环铅酸蓄电池，品牌超威电池，全国联保。

72V 20AH, with 6 large-capacity deep-cycle lead-acid batteries. The brand is Chaowei Battery, which comes with nationwide warranty service.

电机

Motor

72V 1000W  电机；超大功率满盘电机，动力持久强劲，爬坡能力，载重能力强。

72V 1000W motor; It is a super high-power full-disc motor, offering lasting and powerful performance, with strong climbing ability and high load-bearing capacity.

充电器

Charger

72V  充电平稳、耐高温

With 72V, the charging process is stable and it can withstand high temperatures.

充电时间

Charging time

7-9小时

7-9hours

音响

Audio system

电喇叭；警用巡逻扬声器，声音响亮；高科技内置隐藏式喊话器系统，安全、美观、大方。

Electric horn; Police patrol speaker with a loud sound; High-tech built-in hidden public address system, which is safe, aesthetically pleasing and elegant.

车 身 配 置

颜色

Color

高级灰色标准色，客户可定制

Color:Advanced gray standard color, which can be customized by customers.

座椅

Seat

整体式海绵外包皮革座椅，舒适耐用。

Seat: Integrated sponge seat covered with leather, which is comfortable and durable.

车体

Body

钢制车架+塑料外壳

Steel frame + plastic shell

仪表台

Dashboard

多功能液晶数码仪表盘，功能齐全

Dashboard: Multi - function LCD digital instrument panel with complete functions.

车架

微型车车架，高强度钢结构件；整车采用大踏板，前后避震；搭配加固型大货架，结构硬朗、扎实、稳定。保险杠、固定警灯警具专用巡逻警车保险杠，采用一次成型模具，6级电镀精工制造，耐腐蚀，经久耐用，光泽度好，美观漂亮，实用。

The frame is of a micro-car type, made of high-strength steel structural parts. The whole vehicle is equipped with a large pedal and front and rear shock absorbers. It is matched with a reinforced large rack, featuring a tough, solid and stable structure.

The bumper is a special patrol police car bumper for fixing police lights and equipment. It is made by a one-time molding die and manufactured with 6-level electroplating technology. It is corrosion-resistant, durable, has good gloss, looks beautiful and is practical.

灯光及信号

Lights and signals

前照灯，前后转向灯，组合后尾灯，电喇叭；凌厉霸气的水晶的前大灯，按照仿生学原理设计，外形更美观，照明更安全

Headlights, front and rear turn signals, combined rear taillights, and an electric horn. The sharp and imposing crystal headlights are designed in accordance with the principles of bionics, featuring a more aesthetically pleasing appearance and ensuring safer illumination.

后视镜

Rearview mirrors

左右各一手动型外后视镜

Rearview mirrors: One manual external rearview mirror on each of the left and right sides.

底     盘

动力传动系统

Power transmission system

无级调速系统

Stepless speed control system

驱动系统

Drive system

后轴驱动

Rear axle drive

制动系统

Brake system

前碟刹,后鼓刹，性能优越

Front disc brakes and rear drum brakes, with superior performance.

轮胎

Tyre

3.0-10 轮胎，耐磨防刺穿，品牌真空轮胎

3.0-10 tires, wear-resistant and puncture-proof, branded tubeless tires.

外形尺寸 长*宽*高(mm)

Overall dimensions (Length×Width×Height, in mm)

1995×680×1280 mm

整车装备质量

Vehicle curb weight

110kg

整车载荷

Vehicle load-carrying capacity

160kg

轴距

Wheelbase

1350 mm

额定乘员

Rated passenger capacity

2人（含驾驶员）

 2 persons (including the driver).

初速30km/h制动距离

Braking distance at an initial speed of 30km/h

≤6.5 m

最大行驶速度

Maximum driving speed

≤47km/h

续驶里程

Range

≤65Km

最大爬坡度

Maximum gradability

≤20%

Maximum gradability: ≤20%

充电输入电压

Charging input voltage

220v

Charging input voltage: 220V
