品牌Brand

苏华特SUHUATE

型号Type

SHT2409

电 器 系 统   Electrical system

电控Electric control

48V智能化控制系统；无级调速，制动断电，欠压保护，过流保护等性能，稳定。48V 控制器，强劲快速，自动修复。

48V intelligent control system; Stepless speed regulation, braking power off, undervoltage protection, overcurrent protection and other performance, stable. 48V controller, powerful, fast, automatic repair.

电池Battery

48V 40Ah 大容量锂电池48V 40Ah large capacity lithium battery

电机Motor

48V 1200W 永磁直流无刷电机；高效电机，动力强劲，高效节能，续航里程长。48V 1200W permanent magnet DC brushless motor; High efficiency motor, powerful power, high efficiency and energy saving, long driving range.

电路系统Circuit system

全车防水、阻燃插件，骑行更安全

Whole waterproof, flame retardant plug-in, more safe riding

充电器Charger

48V40Ah 锂电充电器，耐用、安全、充电平稳、耐高温

48V40Ah lithium charger, durable, safe, stable charging, high temperature resistance

充电时间Charging time

6-8小时

6-8 hours

车 身 配 置   Body matching

车体Body

钢制车架+塑料外壳Steel frame + plastic shell

仪表Instrument panel

多功能黑莓全面屏数码仪表盘，功能齐全

Multifunctional blackberry Full screen digital dashboard, full of features

车架Frame

锂电、铅酸通用车架，高强度钢结构件；整车采用大踏板，前后避震，结构硬朗、扎实、稳定。Lithium battery, lead-acid general frame, high-strength steel structure; The whole vehicle adopts large pedal, front and rear shock absorber, the structure is strong, solid and stable.

前叉Front fork

液压带阻尼无缝管材质，外加塑料防护套

Hydraulic belt damped seamless tube material, plus plastic protective jacket

灯光及信号Lights and signals

透镜LED大灯，前照灯，前左、右转向灯：组合后尾灯，配置左、右转向灯。电喇叭；凌厉霸气的水晶的前大灯，按照仿生学原理设计，外形更美观，照明更安全

Lens LED headlights, headlights, front left and right turn signals: combined rear taillights, equipped with left and right turn signals. Electric horn; The crystal headlights are designed according to the principle of bionics, which makes the appearance more beautiful and the lighting more safe

P档P file

点动式开关，车辆启动更安全Point switch, vehicle start safer

遥控器及防盗器Remote control unit and burglar alarm

配置智能化遥控器，智能化防盗器Intelligent remote control, intelligent anti-theft device

前减震Front shock absorber

无缝，阻尼，双管液压Seamless, damped, dual hydraulic

后减震Rear shock absorber

倒置结构，带阻尼Inverted structure with damping

车尾箱Boot

外卖专用框Delivery box

底 盘   Bottom plate

动力传动系统Power transmission system

无级调速系统Stepless speed control system

驱动系统Drive system

后轴驱动Rear axle drive

制动系统

Brake system

前碟刹,后碟刹，性能优越

Front disc brake, rear disc brake, superior performance

外形尺寸 长*宽*高(mm)

Size Length * Width * Height (mm)

1760mm×675mm×1090mm

轴距Wheelbase

1250mm

轮胎Tyre

300-10 真空轮胎300-10 vacuum tires

额定乘员Rated occupant

1人

1 people

制动距离Braking distance

≤6.5 m

最大行驶速度Maximum travel speed

≤63km/h

续驶里程Range

≤80Km

最大爬坡度Maximum gradient

≤40°

充电输入电压Charge input voltage

220v
